Product details

Custom-designed by OFF STUDIO and manufactured by Kailh, the MX BCP Switch features glass fibre-free PA66 housing (top and bottom) with a textured finish, delivering a smooth, mellow rebound sound.

Fitted with the original Kailh MX Cream POM stem, it boasts reinforced top housing ribs for tight, stable keystrokes – with minimal stem wobble. A thickened custom bottom housing adjusts total travel and enhances sound depth, paired with Kailh’s updated contact leaf for reduced noise.

Equipped with Kailh’s latest factory lubrication, it retains a dry, textured feel and unique sound profile, ensuring high usability straight out of the box. Note: Slight friction may occur when pressing from the keycap edge due to tight component clearances.
Specifications

Switch Type: Linear

Manufacturer: Kailh

Actuation Force: 52gf

Bottom-Out Force: 63.5g

Pins: 5-Pin

Pre-Travel: 1.4mm

Total Travel: 3.5mm

Materials: Glass Fibre-Free PA66 Top/Bottom Housing, Kailh MX Cream POM Stem

Spring: 20mm Single-Stage Precision Spring

SMD LED: Compatible with SMD LEDs

Lubrication: Factory-Lubed

Sound Profile: Mellow Rebound, Deep Bottom-Out, Reduced Noise

Special Features: Original MX Cream Stem, Tight Component Clearances, Updated Contact Leaf

Inside the box

BCP Linear Switches

Protective Anti-Static Storage Tray

Compatibility

Works with any PCB compatible with Cherry style switches.

5 pins can be modified to 3 pins by clipping off the extra 2 pins if necessary.

Warranty

1 year manufacturer's warranty – further warranty provided at OZO’s discretion depending on the situation
