KeyGeek XLLAB - Full Nylon Linear Switches
KeyGeek XLLAB - Full Nylon Linear Switches
KeyGeek XLLAB - Full Nylon Linear Switches
KeyGeek XLLAB - Full Nylon Linear Switches

Anbieter:Keygeek

KeyGeek XLLAB - Full Nylon Linear Switches

£3.30
Pack Size
Pack Size: 10 Switches
Bottom Out
Bottom Out: 42g
Dispatch Time
Business Transparency: How we operate?

As a small UK business, we handle every order ourselves — no drop shipping involved. Every item we send out goes through a quality control check to make sure you receive exactly what you ordered and in the condition you’d expect.

Some of our products are sourced from local UK suppliers, while others come directly from manufacturers we trust. The dispatch times for each item are clearly shown on the product listing, so you’ll always know whether it’s available for same-day dispatch or if it needs a little extra time before shipping.

We also pride ourselves on providing the best customer support possible. When you contact us, you’ll always be speaking directly to one of the three people who run this business — no automated bots, no outsourced call centres, just real help from people who know and love the products we sell.

Product details

Co-developed by XLLAB and KeyGeek, the Full Nylon Linear Switch is the first with full nylon construction. Its 3.8±0.3mm long travel and custom private mold boost keycap compatibility, avoiding jamming with thick keycaps.
The modified nylon stem and N5 bottom case (hardened via modification) deliver louder, more concentrated bottom-out sound. Nylon’s sound-absorbing trait creates a rich, deep, crisp tone—pleasant, non-overwhelming, and great with or without switch films. It offers good stability and a smooth, dry, straight-up-and-down feel.
A native large light guide column (with light-diffusing powder) provides non-dazzling, excellent lighting. Mold adjustments removed bottom case buckles, solving plugging difficulties for easy switch insertion and removal.
Specifications

Switch Type: Linear (Rich Deep Crisp Sound)

Manufacturer: KeyGeek

Actuation Force: 37g / 45g

Bottom-Out Force: 42g / 53g

Pins: 5-Pin

Pre-Travel: 2.0mm

Total Travel: 3.8mm

Materials: PA66 Top Housing, Modified Nylon Stem, N5 Bottom Case (Full Nylon Construction)

Spring: 22mm Single-Stage Precision KOS Spring

SMD LED: Compatible with SMD LEDs

Lubrication: Factory Pre-Lubricated

Sound Profile: Rich, Deep, Crisp, Pleasant to Listen to (No Overwhelming Noise)

Special Features: First Full Nylon Switch, Custom Private Mold (Improved Keycap Compatibility), Modified Hardened Materials, Native Large Light Guide Column, No Bottom Case Buckles (Easy Plugging), Good Stability

Inside the box

Full Nylon Linear Switches

Protective Anti-Static Storage Tray

Compatibility

Works with any PCB compatible with Cherry style switches.

5 pins can be modified to 3 pins by clipping off the extra 2 pins if necessary.

Warranty

1 year manufacturer's warranty – further warranty provided at OZO’s discretion depending on the situation
