Product details

Keychron Q15 Max Ortholinear Keyboard

Keychron Q15 Max: The Ortholinear Grid, Mastered

Full Aluminum • QMK/VIA • Tri-Mode Wireless • Ortholinear Layout

A grid, not a stagger. Every key aligned. A layout built for pure efficiency. Introducing the Keychron Q15 Max: the ortholinear keyboard that brings a full suite of enthusiast features to this unique, efficient layout. Constructed from a solid block of 6063 aluminum and engineered with a double-gasket design, this compact standout comes equipped with a long list of endgame components.

Keychron Q15 Max Aluminum Build
PREMIUM BUILD

A Foundation of Solid Metal

The first thing you'll notice about the Q15 Max is its weight. This board is crafted from a single piece of 6063 aluminum for maximum stability—no hollow plastic, no shifting on your desk.

The entire case is CNC machined, polished, and sandblasted through more than 24 manufacturing stages to achieve its final form.

A polycarbonate plate and double-gasket mount deliver a cushioned, responsive feel on every actuation.

Keychron Q15 Max Internal Structure
ACOUSTIC ENGINEERING

15-Layer Acoustic System

Inside, a complex 15-layer system of acoustic foams—including IXPE, PET, and Latex—absorbs unwanted pings and refines the sound profile.

The result? A deep, satisfying sound that turns every keystroke into a premium typing experience.

Combined with the double-gasket mount system, the Q15 Max delivers both acoustic excellence and a cushioned feel that high-end keyboards are known for.

Keychron Q15 Max Hot-Swappable
FULL CUSTOMIZATION

Make It Yours

The Q15 Max is designed to adapt to your exact preferences. Hot-swappable sockets accept nearly any 3-pin or 5-pin MX-style switch—no soldering required.

Remap any key, create complex macros, and add extra layers of functionality through VIA or Keychron Launcher web app.

The two programmable knobs can be assigned to anything from volume control and screen brightness to timeline scrubbing in your editing software.

TRI-MODE WIRELESS

Wireless Freedom, No Compromises

With the Q15 Max, that compromise is over. Full QMK and VIA support across all connectivity modes.

At its heart is an ARM Cortex-M4 processor that provides flawless performance across all three connectivity modes:

USB-C Wired

1000 Hz polling rate for zero latency

Bluetooth 5.1

Connect up to 3 devices seamlessly

2.4 GHz Wireless

1000 Hz polling for competitive gaming

All while retaining complete control through QMK and VIA

Gateron Jupiter Switches
PREMIUM SWITCHES

Gateron Jupiter Switches

The fully assembled version comes equipped with Gateron Jupiter switches, pre-lubed from the factory for a smooth feel right out of the box.

A unique LED diffuser design allows the south-facing RGBs to shine brightly, creating stunning per-key lighting effects.

With a lifespan of up to 80 million keystrokes, they're built to last through years of intensive typing.

XDA PBT Keycaps
PREMIUM KEYCAPS

XDA PBT Keycaps

Topping it all off is a set of XDA profile keycaps. Made from durable, oil-resistant PBT plastic with dye-sublimated legends.

Their uniform height is a perfect match for the ortholinear grid, making it easy to rearrange keys without disrupting the look or feel.

For the larger keys, screw-in PCB stabilizers create a more stable and consistent typing experience, reducing rattle and wobble.

What's In The Box

Keychron Q15 Max Package Contents

Premium Components, Assembled

Full Aluminum Construction

CNC-machined 6063 aluminum case through 24+ manufacturing stages for maximum stability and premium feel.

Double-Gasket Mount

Polycarbonate plate with double-gasket mounting system delivers a cushioned, responsive typing feel.

15-Layer Acoustic System

Complex foam system with IXPE, PET, and Latex layers creates a refined, deep sound profile.

QMK/VIA Support

Full programmability across all connectivity modes. Remap keys, create macros, and customize lighting.

Hot-Swappable PCB

Accepts 3-pin or 5-pin MX-style switches. Experiment with different switches without soldering.

Dual Programmable Knobs

Two rotary encoders fully customizable through VIA for volume, brightness, or application-specific controls.

Common Questions

What is an ortholinear layout?

An ortholinear layout arranges keys in a straight grid, unlike the staggered layout found on most keyboards. The goal is to reduce finger travel and create a more consistent, efficient typing motion. It can take some getting used to, but many typists find it more comfortable and faster in the long run.

Is this keyboard good for a beginner to mechanical keyboards?

While the Q15 Max is packed with high-end features, the ortholinear layout presents a learning curve. If you're new to mechanical keyboards and looking for a traditional typing experience, you might consider a standard staggered layout first. However, if you're intrigued by the idea of optimizing your typing and are willing to adapt, the Q15 Max is an excellent, feature-complete choice.

Can I use it with my Mac and Windows PC?

Yes. The keyboard is fully compatible with Mac, Windows, and Linux. It includes keycaps for both macOS and Windows, and you can switch between operating system layouts with a simple toggle.

What is the benefit of the dual knobs?

The two rotary knobs are fully programmable. By default, one might control volume and the other screen brightness. But using VIA software, you can assign them to a huge range of functions, like scrolling, zooming, undo/redo, or application-specific controls, giving you immediate tactile control over your most-used commands.

The Ortholinear Grid, Perfected

The Keychron Q15 Max represents the pinnacle of ortholinear keyboard design. With full aluminum construction, tri-mode wireless with complete QMK support, and a 15-layer acoustic system, it's built for those who value efficiency and refuse to compromise on quality.

Got questions? 🤔

Do you have any questions, or unsure if this product is compatible with your setup?

Specifications

Layout: Ortholinear grid, approx. 66 keys

Body Material: CNC-machined aluminum

Plate Material: Polycarbonate (PC)

Connectivity: Wired USB-C / 2.4 GHz wireless (1000 Hz) / Bluetooth 5.1

Keycap Profile: XDA dye-sub PBT (non shine-through)

Switch Compatibility: Hot-swappable with 3-pin & 5-pin MX-style switches

Firmware: QMK + Keychron Launcher for full customisation

Weight: approx. 1232 g fully assembled

Inclusion: Keyboard kit (fully assembled or barebone variant depending on choice)

Inside the box

1 × Keychron Q15 Max Keyboard (choose variant)
Includes: USB-C cable, Mac/Windows keycap set, user manual

Compatibility

Compatible with Windows, macOS and Linux

Supports layered mapping via QMK and custom macros through Keychron Launcher

Hot-swappable version supports wide range of MX-style switches (Cherry, Gateron, Kailh etc.)

Warranty

1-year manufacturer’s warranty
